Bosman Vision Submersible Flood Pumps

Low footprint, fish-friendly pumps for stormwater networks, drainage and irrigation.

    Fish-friendly by design

    Bosman Vision Pumps are specifically engineered to ensure the safe passage of aquatic life, making them ideal for applications in land irrigation and flood water management. The Vision Series can be retrofit or installed new. Utilising a mixed-flow fan and single-blade impeller, fish mortality is reduced to a low as zero and consistently below 2% in independent trials. Prime Fluid Management has partnered with Bosman Watermangement to deliver unparalleled design, service and support to consultants, Councils and civil contractors in New Zealand.

    Bosman Watermanagement

    Pumping since 1929

    With over 90 years of engineering experience, Bosman Watermanagement is a global leader in sustainable, high-performance water systems. Based in the Netherlands and trusted worldwide, Bosman pump designs have the preservation of waterways and aquatic life at their core.

    •  fish-friendly impeller design
    • water-lubricated bearings
    • minimal groundwork/ no forebay required
    Pumping since 1929
    Bosman Vision Submersibles

    Efficient. Adaptable. Low Maintenance.

    Bosman Vision Series submersible pumps offer efficient, future-ready performance with minimal complexity.

    • Easily upgraded with a higher-powered motor to meet future flow demands
    • Up to 85% hydraulic efficiency
    • Wide, cavitation-free operating range
    • No need for a pilot pump
    Efficient. Adaptable. Low Maintenance.

    Overview of our Bosman Vision Submersible Flood Pumps

    Bosman Vision Metal Casing (MC) Pumps Install the Vision MC Metal Casing pump in new or exiting pump stations. Provides safe fish passage while delivering high-capacity performance.
    • Flow: 12 - 360m3/min
    • Max head: 8m
    • Efficiency: up to 85%
    • Large unobstructed passage
    View Datasheet
    Bosman Vision Concrete Volute (CV) Pumps The Vision CV Concrete Volute pump safely transports aquatic life while delivering high-capacity drainage and irrigation.
    • Flow: 12 - 360m3/min
    • Max head: 8m
    • Efficiency: up to 85%
    • Compact, low noise
    View Datasheet

    Download the Stormwater Product Guide

    Download
    GALLERY

    In the field

    Here are some examples of our solutions being used.
