Tsurumi Pumps
Submersible pumping solutions for drainage, wastewater and demanding fluid environments.
For Demanding Submersible Duties
Tsurumi’s submersible range spans drainage and dewatering, wastewater and sewage, corrosion-resistant pumping and aeration. Different hydraulic designs, materials and configurations help match the range to demanding operating conditions.
Match the Pump to the Duty
Different duties call for different hydraulic and material options.
- Wastewater & Sewage: Vortex for solids passage, channel for general wastewater, and cutter types where fibrous material creates a blockage risk.
- Drainage & Dewatering: Portable for standard duties, abrasion-resistant for grit, low-level for residual water and high-head for greater lifts.
- Corrosion-Resistant: Resin, stainless steel or titanium – chosen around chemistry and chloride exposure.
- Aeration: Selected around oxygen transfer, tank depth and mixing requirements.
Protection Against Common Failure Points
Tsurumi targets seal lubrication, moisture ingress, abrasion and corrosion through specific design features and material choices.
- Oil Lifter System: Keeps the mechanical seal lubricated as oil levels drop – helping extend seal life.
- Anti-Wicking Cable Entry: Helps stop moisture travelling along the cable into the motor.
- Wear and Material Options: High-chromium iron resists abrasive wear – with resin, stainless steel and titanium options for corrosive environments.
.jpg)
See the Tsurumi BN Series Cutter Pump in Action
Take a look how the BN Series wastewater cutter pump breaks down difficult fibrous material to help reduce blockage risk.
Overview of our Tsurumi Range
Tsurumi submersible drainage pumps cover portable, abrasion-resistant and high-head dewatering for clean to lightly contaminated water with sand and silt.
- Max flow: 720m³/hr
- Max head: 230m
- Power: 0.75-150kW
- Materials: aluminium alloy | high-chromium iron | grey cast iron
Submersible wastewater and sewage pumps use channel, vortex and cutter impellers to handle solids and fibrous material across industrial duties.
- Max flow: 6,600m³/hr
- Max head: 70m
- Max solids handling: up to 100mm
- Materials: cast iron
Corrosion-resistant submersible pumps for aggressive wastewater, chemicals and seawater where cast iron is unsuitable.
- Max flow: 124.8m³/hr
- Max head: 44m
- Discharge sizes: 40-80mm
- Materials: resin | stainless steel | titanium
Tsurumi aerators provide oxygen transfer and circulation to support solids suspension and biological treatment in wastewater and process water.
- Max air flow rate: 528m3/hr
- Max water depth: up to 6m
- Power: 0.75-40kW
- Air inlet bore: 25-150mm
Speak to an expert
Choosing the right submersible pump depends on what's in the water, the duty and the site conditions. Tell us about the application and we'll help identify the right Tsurumi option.
Tsurumi Pumps FAQs
Selection depends on the solids, fibres and blockage risk. Vortex designs favour freer solids passage – while cutter and smashing cutter designs reduce fibrous material before it passes through the pump.
Channel hydraulics suit wastewater duties where solids passage is required without cutting.
Titanium is worth considering for seawater and high-chloride environments where conventional stainless steels may be vulnerable to localised corrosion. Final material choice should reflect fluid chemistry and wetted-component compatibility.
Tsurumi offers dedicated high-head drainage ranges – including KTZ and LH Series options, with some models extending into extra high-head duties. Selection depends on the required flow, total head and operating conditions.
Contact us at Prime to find out more.
The Oil Lifter supplies lubricating oil to the upper mechanical seal faces as oil levels fall – helping maintain seal lubrication and extend seal life.
Titanium models are designed for seawater and other chloride-rich duties where conventional stainless steel may be vulnerable to localised corrosion.
See our marine pump solutions – or tell us about the installation and we'll help confirm the right model and material.
