Sludge & Slurry Submersible Pumps

Your pit dewatering could do better.

Sludge and slurry submersible pumps are specialised pumps built to withstand highly abrasive fluids. They are constructed from hard metals and abrasion-resistant linings, with added features to prevent obstruction, overheating, and excessive wear.

These pumps are ideal for moving thick, solid-laden liquids such as wastewater and sludge from ponds, tanks, or treatment facilities. Whether you're managing water transfer on a construction site, cleaning out a sediment-filled pond, or handling industrial wastewater, submersible sludge pumps offer a reliable and portable solution.

Avalible for both hire and sale across New Zealand, these pumps are commonly used for dewatering, desludging, and transferring heavy liquids where durability and efficiency are critical.

SYSTEM DESIGN

Identify your performance drains

You know your quarry. We know our products. Together, we can identify performance drains and problem products that are hindering maximum productivity.
At Prime Fluid Management, productivity assessments are a first step in our solutions pathway.

NEW TECHNOLOGY

Working smarter

At Prime Fluid management we are look for technological advances in our products – design, engineering and connectivity features that will help you to:

Optimise resource
Minimise handling and movement
Improve operational safety
Meet discharge and environmental obligations
Reduce extraction costs

Overview of our Submersibles

Grindex Sludge Pumps

The Solid, Salvador, Senior and Sandy models, designed for continuous, unattended operation where reliability is critical and solids content is high.

Size: 50mm – 100mm (2” – 4”)
Max flow: 24L/s
Max head: 38mwc
Max solids: 80mm

Grindex Slurry Pumps

Constructed for maximum wear-resistance, the Grindex Bravo range handles highly abrasive liquids with a pH tolerance of 5.5 – 14. Agitators are built-in in some models.

Size: 100mm – 150mm (4” – 6”)
Max flow: 130L/s
Max head: 45mwc
Max solids: 40 mm

Proril Sand & Slurry Pumps

A rugged and cost-effective solution the Proril Stormy series feature high chrome impellers, agitators and wear plates to withstand tough slurry transportation.

Size: 75mm – 200mm (3” – 8”)
Max flow: 110L/s
Max head: 30mwc
Max solids: 40mm

Heavy-duty Electric Dredge Pumps Move large volumes of abrasive materials without clogging or excessive wear. Available with advanced control panels for remote monitoring.

Size: 75mm – 300mm (3”-12”)
Max flow: 50,000 L/min
Max head: 120m
Solids: 120mm

Hydraulic Dredge Pumps

Suited to high head and heavy dewatering, dam or pond cleaning, extraction and coastal protection.
Significant economy over traditional methods.

Size: 100mm – 350mm (4”-14”)
Max flow: 66,700 L/min
Max head: 68m
Solids: 120mm

Grindex Stainless Sludge Submersibles VHandling pH 2 -10, and solids up to 10mm, Grindex INOX stainless steel submersibles handle corrosive dewatering environments.
Constructed from AISI 316 stainless steel.

Size: 2” – 6”
Max flow: 130L/s
Max head: 200m
Solids: 80mm

Proril Stainless Submersibles The Proril X-Smart and X-Vox ranges feature corrosion-resistant impellers with large free passage.
Contact areas are constructed from 304 or 316 stainless steel.

Size: 2” (50mm)
Max flow: 43m3/h
Max head: 18mwc
Solids: 40mm
